$440.00
A high-quality veterinary orthopedic instrument set designed for fracture fixation. Made from durable stainless steel, it includes essential tools for precise and efficient surgery. Ideal for large fragment plating systems.
$440.00
Astrin Surgical Return Policy
We offer a 30-Day Free Return Policy for your convenience.
Items must be returned within 30 days in original packaging (opened packages accepted).
Contact our support team for return instructions.
Refunds are processed within 5-7 business days after inspection.
Note: Used or damaged items are non-returnable unless defective.
For assistance, reach out to our support team!
Introducing Large Fragment Instrument Set of ASTRIN SURGICAL. Specially made for treatment of bones of Animals. A large fragment instrument set is a collection of surgical instruments used to fixate large bone fragments, typically in the femur, tibia, or humerus. These instruments are used in orthopedic surgeries such as open reduction and internal fixation (ORIF) of fractures, which involve fixing broken bones using screws, plates, and other devices.
|
NO.
|
Product
|
Qty.
|
|
|
1
|
Neutral and Load Drill Guide Φ3.2
|
1
|
|
|
2
|
Drill & Tap Guider (Φ4.5/Φ6.5)
|
1
|
|
|
3
|
Drill & Tap Guider (Φ3.2/Φ4.5)
|
1
|
|
|
4
|
Drill Bit (Φ4.5*115mm)
|
1
|
|
|
5
|
Drill Bit (Φ4.5*115mm)
|
1
|
|
|
6
|
Drill Bit (Φ3.2*115mm)
|
1
|
|
|
7
|
Drill Bit (Φ3.2*115mm)
|
1
|
|
|
8
|
Depth Gauge (0-90mm)
|
1
|
|
|
9
|
Periosteal Elevator 15mm
|
1
|
|
|
10
|
Obilique Reduction Forcep (230mm)
|
1
|
|
|
11
|
Periosteal Elevator 8mm
|
1
|
|
|
12
|
Sharp Reduction Forcep (200mm)
|
1
|
|
|
13
|
Silicon Handle Screwdriver Hexagonal 3.5mm
|
1
|
|
|
14
|
Self-centering Bone Holding Forcep (270mm)
|
2
|
|
|
15
|
Retractor Width 40mm/18mm
|
1
|
|
|
16
|
Countersink Φ8.0
|
1
|
|
|
17
|
Hollow Reamer Φ8.0
|
1
|
|
|
Extraction Screw Hexagonal 3.5mm Conical
|
1
|
||
|
18
|
Tap Cortex 4.5mm
|
1
|
|
|
Tap Cancellous 6.5mm
|
1
|
||
|
19
|
Bending Iron
|
1
|
|
|
20
|
Aluminium Box
|
1
|
A large fragment instrument set typically includes the following components:
Reduction Instruments
Reduction instruments are used to manipulate bone fragments into the proper position. These instruments include bone reduction forceps, pointed reduction forceps, and bone-holding forceps.
Drilling instruments are used to create holes in the bone for the placement of screws and other fixation devices. These instruments include a hand drill, a drill bit set, and a drill guide.
Plate and screw instruments are used to secure the bone fragments in place. These instruments include bone plates, screws, and a screwdriver set.
Bone graft instruments are used to harvest bone grafts from other parts of the body for use in the repair of bone defects. These instruments include bone curettes and bone gouges.
A large fragment instrument set has various benefits compared to other forms of surgical instruments. They include:
Large fragment instrument sets are made to deal with orthopedic procedures on large bone fragments, providing precision and accuracy when conducting the operation.
A large fragment instrument set can also save time for orthopedic procedures, as it contains all the instruments required for the procedure in one set.
Cost-Effective
It is cost-effective to use a large fragment instrument set compared to buying separate instruments for every procedure.
